MaC-2 DOL Motor Starter (DMC)

MAGNUM DMC MaK-1 DIRECT ON-LINE MOTOR STARTER is a powerful controlling device for your motor/pump made with heavy duty components, which switches and protects your device from hazards caused due to over-current. DMC material housing for contactor and relay makes the components withstand higher temperatures

Product Video

MaC-2 DOL Motor Starter (DMC) is manufactured for better heat resistance as contactor and relay, both are housed in dmc housing. Magnum MaC-2 DOL Starters are built for top performance.

01DMC based MaK-1 Contactor with wide voltage band is designed for exceptional endurance.
02Fitted with DMC housed MaK-1 type relay for reliable overload protection.
03Ergonomic design with aesthetic looks.
04A latch on the push button can keep the stop button locked, thus preventing accidental starting.
05Hum – Free.
06Easy & quick mounting.
07Encapsulated coil to with-stand wide voltage fluctuations.
08Fitted with earthing screw for a safety measure.
09Manually reset facility after trip.
10On/Off indications can be visible through the given window.

Product Details:

Power	Up to 10 H.P
Starter Type	Direct-On-Line Starter
Voltage	440 V
Coil Voltage	440 V
Current Rating	Up to 32 A
Phase	Three Phase
Frequency	50 Hz
Current Type	AC
Warranty	Up to 12 months
Condition	New
Material	Mild steel Powder Coated
Brand	Magnum

Magnum Three Phase Direct On-Line Motor Starters are reliable “Workhorses” for domestic, agricultural and industrial applications. Motor Starters are also found in many applications such as drainage, sewage pumping, general industrial pumping and slurry pumping.

Also used in

Pumps
Fans
Cooling Compressors
Stirrers and mixers

Data Sheet Download
